LESU 1/14 RC forklift Aoue-LD160S Sond Light System W/O Battery Charger Metal Remote Control Hydraulic Truck Models

LESU 1/14 RC forklift Aoue-LD160S Sond Light System W/O Battery Charger Metal Remote Control Hydraulic Truck Models



Regular price $2,538.90 USD
Regular price Sale price $2,538.90 USD
Sale Sold out

Brand: LESU
Item condition: New, Assembled and Painted.
Scale: 1/14
Material: Metal, Plastic
Car Shell Material: aluminum alloy+stainless steel (door can be opened)
Size: 464*192*269mm
Drive Type: front-wheel drive
Wheelbase: 235.3mm
Axle reduction ratio: 1:3
Front-wheel specification/mm: diameter 82 * width 46
Rear wheel specification/mm: diameter 82 * width 46
Maximum pressure of hydraulic workstation/mpa: 3.5
Rated pressure of hydraulic workstation/mpa: 3
Motor speed (r/min): 196; 12V
Color: Red

The package includes:
1/14 RC Hydraulic Forklift Model
Hydraulic System (With 6CH Reversing Valve)
Light System
Sound System

???¡§???The Package Does Not Include:
Remote Controller and Receiver
Hydraulic Oil

1. Metal CNC shell
2. Front-wheel drive, built-in differential of the front axle.
3. Rear steering axle with suspension.
4. Precision hydraulic system: more coordinated, smooth and linear action.
5. Hydraulic front fork and hydraulic gantry.
6. Front fork width is adjustable.
7. 6-way reversing valve hydraulic system, the reserved 4-way reversing valve can use a variety of upgraded parts.
8. Double-row precision simulation chain, which is more stable and reliable.
9. Door can be opened.
10. The body rear is attached with a towing hook.
11. The gantry is equipped with a built-in bearing, which makes the action more coordinated, smooth, stable and reliable.
12. High simulation light and sound system.

Parameters (unit: mm):
A. Height from the top of the cockpit to the ground: 235.9
B. Maximum height of expansion frame from the ground: 405
C. Body length: 325.4
D. Wheel base of tire: 235.3
E. Maximum height of lifting front fork: 301.7
F. Body width: 192
G. Maximum lateral extension distance of front fork: 152.4
H. Maximum one-way extension distance of front fork: 59
I. Minimum ground clearance: 15
J. Tyre center distance: 133.3
K. Distance between front fork and drive wheel center: 78.1
L. Gantry height: 269
M. Rear hatch cover ground clearance: 152.6
N. Front fork thickness: 5
O. Minimum pivot point distance: 100
P. Turning radius: 330
Q. Maximum distance from rear wheel suspension to the ground: 3

???¡§???If you have any questions or are not sure whether it is the correct item that you want, pls feel free to ask me before purchasing.

???¡§???Shipping Policy:
1. We ship to most countries of the world. But if you are from Israel, Brazil, South America, and the Middle East, please contact me first, because sometimes we can not ship to your country because of shipping limitations.
2. Shipping takes 6-18 business days.

???¡§???Return Policy:
We only wish to deal with a serious buyer.
Please don't open a dispute or return request if your products got any problems. Please contact us, we will help you to solve the problems, and we have professional technicians to provide technical support.

???¡§???International Buyers Please Notes
Import duties, taxes, and charges are not included in the item price or shipping cost, these charges are the buyers' responsibility. But in some countries, we can help you to clear the customs and pay the tax for you, please contact me to know more information.
Please check with your country's customs office about the tax before buying or bidding.
